Room temperature sensor with operating elements in the surface switch range THERMASGARD® FSTF LM235Z P
THERMASGARD® FSTF LM235Z P
SKU 1101-5022-1001-162
EAN 4 251325 604152
Product group: WG01
In stock
, available in 3-5 working days
Shipping calculated at checkout.
Regular price
88,98 €
Regular price
Sale price
88,98 €
Livraison en 2 jours en France
5 ans de garantie
Demander une remise quantitative
Product description
- passive
- -30...+60 °C
- 2-wire connection
- potentiometer
The THERMASGARD room sensor connection diagram FSTF - xx ® FSTF is used for air temperature measurement or setpoint adjustment, presence detection or as a room control unit, as a control panel with temperature sensor, buttons, potentiometer, status indicators (LED).
The flush-mounted sensor is installed in high-quality surface switch programs, preferably from Gira, Berker, Merten, Jung, Siemens or Busch-Jaeger (using flush-mounted adapters), either individually or in combination with light switches, sockets, etc.
It is used in non-aggressive, dust-free environments, in refrigeration, air conditioning and clean room technology, in interiors such as living rooms, offices, hotels, etc.
The flush-mounted sensor is installed in high-quality surface switch programs, preferably from Gira, Berker, Merten, Jung, Siemens or Busch-Jaeger (using flush-mounted adapters), either individually or in combination with light switches, sockets, etc.
It is used in non-aggressive, dust-free environments, in refrigeration, air conditioning and clean room technology, in interiors such as living rooms, offices, hotels, etc.
Technical data
| Sensor | LM235Z |
| Type of function | Measurement of temperature |
| Measured variables | Temperature, passive temperature |
| Display | No |
| IP rating | IP20 |
| Output variant | - |
| Housing | GIRA System 55 |
| Measuring range | -30...+60 °C |
| Features | Potentiometer |
