Room pendulum humidity and temperature sensors HYGRASGARD® RPFTF-25-U

Name: HYGRASGARD® RPFTF-25-U
Brand: S+S Regeltechnik
SKU: 1201-7121-1000-100
Price: 480.36 EUR
Availability: InStock

HYGRASGARD® RPFTF-25-U

SKU 1201-7121-1000-100 EAN 4 251325 611372 Product group: WG02

In stock , available in 1-3 working days

Shipping calculated at checkout.

480,36 €

Quantity

Livraison en 2 jours en France
5 ans de garantie
Demander une remise quantitative

View full details

Product description

0...100 % RH-35…+35 °C -35…+75 °C 0…+50 °C 0…+80 °C<\/li>
Humidity accuracy: ± 1.8 % / Temp.: ± 0.2 K<\/li>
0-10V<\/li>
IP65<\/li><\/ul>
The calibratable room humidity and temperature sensors HYGRASGARD® RPFF - 25 / RPFTF - 25 with plug-in metal sinter filter and housing made of impact-resistant plastic are available with/without display.

They measure the relative humidity and/or temperature of the air and convert the measured variable into a standard signal of 0-10 V or 4...20 mA. The transmitters have four switchable temperature ranges and are used in non-aggressive, dust-free environments, in refrigeration, air conditioning and clean room technology, in hotels, technical rooms, assembly and conference facilities. They are designed for the precise measurement of temperature and humidity. A digital, long-term stable sensor is used as the measuring element for humidity and temperature. The sensor is suitable for ceiling and duct mounting or for device installation and is calibrated at the factory. Fine adjustment by a specialist is possible depending on the environment.

Technical data

Measured variables	Temperature, relative humidity
Power supply	24 V AC (± 20 %) and 15…36 V DC
Display	No
Output version	Cable gland
Additional measured size to °C + %RH	+ °C
Humidity sensor tolerance	1.8 %
